HMT Max 30 Magnetic Drilling Machine

Calculating latest stock

Product Overview

  • The Max 30 magnetic drill weighs just 8.5kg, making it probably the lightest and most compact magnetic drill available in its class.


    With its powerful 900 Watt high speed motor, the Max 30 is perfectly optimised for broaching the most common structural sizes of 12-30mm, particularly when used with CarbideMax TCT Cutters.

    The Max-30 also has an exceptional stroke compared to other machines in its class, capable of taking cutters or magnetic drill bits up to 70mm long.

    Each machine is supplied in a robust plastic site carrying case with foam inserts to help protect the machine and accessories.

    Accessory pack contains a removable internal coolant system bottle of broaching lubricant, removable metal guard, safety chain, 4 hex keys.


    Annular Hole Cutters: 12 – 30mmø

    Twist Drill Range: 3 – 13mm

    Length: 275mm

    Width: 170mm

    Height Adjustable: 293 – 383mm

    Stroke: 90 mm

    Magnet dimensions (L X W) 160 x 80mm

    Magnetic Force: 1200 kg

    Motor Power: 900 W

    No load speed: 775 RPM

    Arbor 19,05 mm (¾”) Weldon

    Weight: 8.5kg
