Leica Lino L6R 360° Multi Line Laser Level

Calculating latest stock
LINO L6R MULTI LINE LASER LEVEL
Code: 34286
Manufacturers Part No: L6RKIT
Order For Delivery
Select the required delivery time and method at checkout.
Total Stock Available:1
£599.38 each
exc. VAT
£719.26 each
inc. VAT
Add to order


Product Overview

  • The Leica Lino L6R 360° Multi Line Laser Level is a self-levelling red multi line laser with 360° laser line projection for multi-directional alignment—perfect for indoor applications. The laser’s vertical lines are easily adjusted (± 10°) once the plumb point is set.


    Features:

    Working range: The 360° laser lines have an operating range of up to 25 meters / 82 feet, depending on lighting conditions. This means that the Lino L6R achieves laser line projections of up to 50 meters / 164 feet in diameter. This range can be easily extended up to 140 meters / 460 feet by using the RGR200 laser receiver.

    Construction site proof: The Lino L6R is designed for tough environments. It is shock absorbent and protected against dust and splash water (IP54).

    Multi-directional alignment: You can position the cross section (plumb point) of the two vertical laser lines where it is required and then rotate the two horizontal laser lines by ± 10° while the position of the plumb point stays in place. This allows you to position the laser lines of the Lino L6R much faster.

    Magnetic adapters: Magnetic adapters allow for easy positioning to wall moldings, metal poles, and bars; perfect for suspended ceiling installations, transferring reference heights and complex drywall installations.

    Preferred settings: You can individually select each red 360° laser line and its power mode to be turned on or off when the device starts up; meaning your 3×360° laser remembers your preferred settings on set up.

    Self-levelling: The Lino L6R is a self-levelling multi- line laser. This means it automatically adjusts its positioning up to ± 4° when slightly out of level and no manual alignment is needed.

    Specification:

    Beam horizontal: 360°

    Beam vertical: 2 x 360°

    Intersection points: up, down, right, left, front, back (90° / 180°)

    Range / diameter: 25 m / 50 m (82 ft / 164 ft)

    Levelling accuracy: ± 0.2 mm/m (± 0.002 in/ft)

    Horizontal- and Vertical line accuracy: ± 0.3 mm/m (± 0.004 in/ft)

    Intersection point accuracy: ± 0.2 mm/m (± 0.002 in/ft)

    Self-levelling range: ± 4°

    Self-levelling time: < 3 sec

    Fine adjustment: ± 10° around vertical intersection point

    Out-of-level warning: yes – blink lines every 5 s

    Levelling: pendulum (lockable)

    Laser: 635 nm / class 2 (acc. to IEC 60825-1)

    Protection class: IP54 (dust and splash water)

    Battery type:   3xAA Alkaline

    Lino Li-Ion battery pack

    5200 mAh / 18.7 Wh

    or 3xAA Alkaline

    Laser line intensity (selectable)L 100 %, 75 %, 50 %

    Operating time with Li-Ion: up to 36 h (3 beam, 50 % power)

    Operating time with Alkaline: up to 25 h (3 beam, 50 % power) / up to 25 h (3 beam, 50 % power)

    Dimensions: 124 x 107 x 154 mm (4.88 x 4.21 x 6.06 in)

    Weight: 781 g (1.71 lbs)

    Operation temperature: -10 to +50° C (14 to 122° F)

    Storage temperature : -25 to +70° C (-13 to +158° F)

    Laser line width @ 5 m (16.4 ft) distance: < 2 mm (< 0.08 in)

    Tripod thread: 1/4 in (5/8 in with adapter)

    Pulse power for receiver: yes

    3 Years Warranty on all Leica Measuring Equipment when registered.
