Metabo UHEV2860-2 28mm 4-Function SDS Plus Hammer Drill
Product Overview
-
The Metabo UHEV 2860-2 is a heavy duty ‘Multi Hammer’ 4-function SDS Plus rotary hammer drill with a 2 speed gear box and Metabo S-automatic clutch for operator safety.
Read more
Features:
4 Function multi-hammer for hammer drilling, drilling without impact in two speeds and chiseling.
Metabo Quick: quick change between SDS Plus hammer chuck and keyless chuck for drilling in wood and metal.
Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customized speeds, which remain constant under load
Thumbwheel for preselection of the speed and impact rate.
Two-speed gear unit: two drilling speeds for effective drilling in wood and metal.
Metabo Marathon motor with dust protection for long service life.
High performance hammer action, precisely mounted in a housing made of aluminium alloy: long-lasting and robust.
Perfect ergonomics thanks to the center of gravity being near the hand and optimised handle contour.
Bottom switch protected against damage and dust.
Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly.
Restart protection: prevents unintentional start-up after power supply interruption.
Lockable switch for comfortable working in continuous operation.
Cable-protecting ball joint for optimal freedom of motion when working.
Specification:
Input: 1,100 W Motor
No Load Speed: 0 – 900 /0-2100 rpm
Impact Rate: 0 – 4,500 bpm
Single Blow Energy: 0 – 3.4 joules
Max. Drilling in Steel: 13 / 6mm, Wood: 35 / 30mm, Concrete: 28mm
Weight 3.3 kg
Vibration:
Drilling in metal 4.3 m/s²
Uncertainty of measurement K 1.5 m/s²
Hammer drilling concrete 13.5 m/s²
Uncertainty of measurement K 1.5 m/s²
Chiseling 7.2 m/s²
Uncertainty of measurement K 1.5 m/s²
Noise emission:
Sound pressure level 90 dB(A)
Sound power level (LwA) 99 dB(A)
Uncertainty of measurement K 3 dB(A)
3 Years Warranty on all Metabo Power Tools when registered.
