Witt RF53N Flash Back Arrestors Non-Resettable
Product Overview
-
WITT RF53N flashback arrestor offers reliable protection against dangerous reverse gas flow and flashbacks according to EN 730 / ISO 5175-1. These non-resettable arrestors are designed for the protection of cylinder regulators, tapping points and distribution lines, high flow oxy/fuel gas cutting & welding.
Read more
Features:
The large surface area flame arrestor FA of stainless steel construction, extinguishes any dangerous flashback entering the device in any direction.
A temperature sensitive cut-off valve TV extinguishes sustained flashbacks long before the internal temperature of the arrestors reaches a dangerous level.
The spring loaded non-return valve NV prevents slow or sudden reverse gas flow forming explosive mixtures in the gas supply.
These flashback arrestors may be mounted in any position or orientation.
A filter at the gas inlet protects the arrestor against dirt contamination, extending the service life.
Only one piece of equipment may be connected to a single Flashback Arrestor.
Certification BAM/ZBA/003/04
Every RF53N arrestor is 100% tested.
Specification:
Maximum working pressure fuel gases.
Acetylene (A) 1.5 bar
Town gas (C) 5.0 bar
Natural gas (M) 5.0 bar
LPG (P) 5.0 bar
Hydrogen (H) 3.0 bar
Fitting G 3/8 LH
Maximum working pressure gases
Oxygen (O) 30.0 bar
Compressed air (D) 30.0 bar
Fitting G 3/8 RH
Maximum ambient working temperature is 70 °C / 158 °F
Size 25.5mm x 82 mm.
Weight 191gram
